GAMS Language

Sets

Sets are the basic building blocks of a GAMS model, corresponding exactly to the indices in the algebraic representations of models. The Transportation example above contains just one Set statement:



Sets
       i   canning plants   / Seattle, San-Diego /
       j   markets          / New-York, Chicago, Topeka / ;



The effect of this statement is probably self-evident. We declared two sets and gave them the names $i$ and $j$. We also assigned members to the sets as follows:

$i =$ {Seattle, San-Diego}

$j =$ {New-York, Chicago, Topeka}.

Note the use of forward slashes ("/") for surrounding the list of set members. In mathematical notation this would be done with curly braces instead.

Parameters

Parameters are one way of entering data in GAMS. In this case, the parameters $a$ and $b$ are defined over the sets $i$ and $j$.



Parameters
       a(i)  capacity of plant i in cases
         /    Seattle     350
              San-Diego   600  /
       b(j)  demand at market j in cases
         /    New-York    325
              Chicago     300
              Topeka      275  / ;



GAMS lets you place explanatory text (shown in lower case) throughout your model as you develop it. Your comments are automatically incorporated into the output report at the appropriate places.

Table

Data can also be entered in convenient table form. GAMS lets you input data in their basic form - transformations are specified algebraically.



Table  d(i,j)  distance in thousands of miles
                  New-York       Chicago      Topeka
    Seattle          2.5           1.7          1.8
    San-Diego        2.5           1.8          1.4  ;



Scalar

Constants can simply be declared as scalars:



Scalar f  freight in dollars per case per thousand miles  /90/ ;



Data Manipulation

When data values are to be calculated, you first declare the parameter, give it a symbol and optionally index it, then give its algebraic formulation. GAMS will automatically make the calculations.



Parameter
       c(i,j)  transport cost in thousands of dollars per case ;
c(i,j) = f * d(i,j) / 1000 ;



Variables

Decision variables are expressed algebraically, with their indices specified. From this general form, GAMS generates each instance of the variable in the domain. Variables are specified as to type: FREE, POSITIVE, NEGATIVE, BINARY, or INTEGER. The default is FREE. The objective variable, z here, is simply declared without an index.



Variables
     x(i,j)  shipment quantities in cases
     z       total transportation costs in thousands of dollars ;
Positive variables x ;



Equations

Objective function and constraint equations are first declared by giving them names. Then their general algebraic formulae are described. GAMS now has enough information from data entered above and from the algebraic relationships specified in the equations to automatically generate each individual constraint statement. An extensive set of tools enables you to model any expression that can be stated algebraically: arithmetic, indexing, functions and exception-handling logic.

=E= indicates equal to
=L= indicates less than or equal to
=G= indicates greater than or equal to



Equations
     cost        define objective function
     supply(i)   observe supply limit at plant i
     demand(j)   satisfy demand at market j ;
cost ..        z  =e=  sum((i,j), c(i,j)*x(i,j)) ;
supply(i) ..   sum(j, x(i,j))  =l=  a(i) ;
demand(j) ..   sum(i, x(i,j))  =g=  b(j) ;



Model statement

The model is given a unique name, here TRANSPORT, and the modeler specifies which equations should be included in this particular formulation. In this case we specified ALL which indicates that all equations are part of the model. This would be equivalent to MODEL TRANSPORT /COST, SUPPLY, DEMAND/. This equation selection enables you to formulate different models within a single GAMS input file, based on the same or different given data.



Model transport /all/ ;



Solve statement

The solve statement tells GAMS which model to solve, selects the solver to use, indicates the direction of the optimization, either MINIMIZING or MAXIMIZING, and specifies the objective variable.



Solve transport using LP minimizing z ;
