NLPEC

Introduction

The GAMS/NLPEC solver, developed jointly by Michael Ferris of UW-Madison and GAMS Development, solves MPEC and MCP models via reformulation of the complementarity constraints. The resulting sequence of NLP models are parameterized by a scalar \(\mu\) and solved by existing NLP solvers. The resulting solutions are used to recover an MPEC or MCP solution.

GAMS/NLPEC serves a number of purposes. In many cases, it is an effective tool for solving MPEC models, the first such tool available within GAMS. It also serves as a way to experiment with the many reformulation strategies proposed for solving MPEC and MCP models. Without something like NLPEC (and a library of models to test with) a comprehensive and thorough test and comparison of the various reformulation strategies would not be possible. To better serve these purposes, NLPEC has an open architecture. The model reformulations are written out as GAMS source for solution via an NLP solver, so it is possible to view this source and modify it if desired.

A brief note about notation is in order. The GAMS keyword positive is used to indicate nonnegative variables. The same holds for nonpositive variables and the GAMS keyword negative.

Usage

GAMS/NLPEC can solve models of two types: MPEC and MCP. If you did not specify NLPEC as the default MPEC or MCP solver, use the following statement in your GAMS model before the solve statement:

  option MPEC=nlpec; { or MCP }

You can also make NLPEC the default solver via the command line:

  gams nash  MPEC=nlpec MCP=nlpec

You can use NLPEC with its default strategy and formulation, but most users will want to use an options file (Section Options) after reading about the different types of reformulations possible (Section Reformulation). In addition, an understanding of the architecture of NLPEC (Section Open Architecture) will be helpful in understanding how GAMS options are treated. Although NLPEC doesn't use the GAMS options workspace, workfactor, optcr, optca, reslim, iterlim, and domlim directly, it passes these options on in the reformulated model so they are available to the NLP subsolver.

Reformulation

In this section we describe the different ways that the NLPEC solver can reformulate an MPEC as an NLP. The description also applies to MCP models: just consider MCP to be an MPEC with a constant objective. The choice of reformulation, and the subsidiary choices each reformulation entails, are controlled by the options described in the section on Setting the Reformulation Options and referenced throughout this section.

The original MPEC model is given as:

\begin{equation} \tag{1} \min_{x \in \mathbf{R}^n, y \in \mathbf{R}^m} f(x,y) \end{equation}

subject to the constraints

\begin{equation} \tag{2} g(x,y) \leq 0 \end{equation}

and

\begin{equation} \tag{3} y \text{ solves } \mathrm{MCP}(h(x,\cdot), \mathbf{B}) . \end{equation}

In most of the reformulations, the objective function (1) is included in the reformulated model without change. In some cases, it may be augmented with a penalty function. The variables \(x\) are typically called upper level variables (because they are associated with the upper level optimization problem) whereas the variables \(y\) are sometimes termed lower level variables.

The constraints (2) are standard nonlinear programming constraints specified in GAMS in the standard fashion. In particular, these constraints may be less than inequalities as shown above, or equalities or greater than inequalities. The constraints will be unaltered by all our reformulations. These constraints may involve both \(x\) and \(y\), or just \(x\) or just \(y\), or may not be present at all in the problem.

The constraints of interest are the equilibrium constraints (3), where (3) signifies that \(y \in \mathbf{R}^m\) is a solution to the mixed complementarity problem (MCP) defined by the function \(h(x,\cdot)\) and the box \(\mathbf{B}\) containing (possibly infinite) simple bounds on the variables \(y\). A point \(y\) with \(a_i \leq y_i \leq b_i\) solves (3) if for each \(i\) at least one of the following holds:

\begin{equation} \tag{4} \begin{array}{c} h_i(x,y) = 0 \\ h_i(x,y) \geq 0, \; y_i = a_i; \\ h_i(x,y) \leq 0, \; y_i = b_i . \end{array} \end{equation}

As a special case of (4), consider the case where \(a = 0\) and \(b = +\infty\). Since \(y_i\) can never be \(+\infty\) at a solution, (4) simplifies to the nonlinear complementarity problem (NCP):

\begin{equation} \tag{5} 0 \leq h_i(x,y), 0 \leq y_i \text{ and } y_i h_i(x,y) = 0, i=1,\ldots,m \end{equation}

namely that \(h\) and \(y\) are nonnegative vectors with \(h\) perpendicular to \(y\). This motivates our shorthand for (4), the "perp to" symbol \(\perp\):

\begin{equation} \tag{6} h_i(x,y) \ \ \perp \ \ y_i \in [a_i, b_i] \end{equation}

The different ways to force (6) to hold using (smooth) NLP constraints are the basis of the NLPEC solver.

We introduce a simple example now that we will use throughout this document for expositional purposes:

\[ \begin{array}{rc} \displaystyle \min_{x_1,x_2,y_1,y_2} & x_1 + x_2 \\ \text{subject to} & x_1^2 + x_2^2 \leq 1 \\ & y_1 - y_2 + 1 \leq x_1 \perp y_1 \geq 0 \\ & x_2 + y_2 \perp y_2 \in [-1,1] \end{array} \]

This problem has the unique solution \(x_1 = 0\), \(x_2 = -1\), \(y_1 = 0\), \(y_2 = 1\). Note that \(f(x,y) = x_1 + x_2\) and \(g(x,y) = x_1^2 + x_2^2 - 1\) are the objective function and the standard nonlinear programming constraints for this problem. The function \(h(x,y)\) is given by:

\[ h(x,y) = \left[ \begin{array}{c} x_1 - y_1 + y_2 - 1 \\ x_2 + y_2 \end{array} \right] \]

and

\[ a = \left[ \begin{array}{c} 0 \\ -1 \end{array} \right], \;\; b = \left[ \begin{array}{c} \infty \\ 1 \end{array} \right] . \]

This example is written very succinctly in GAMS notation as:

$TITLE simple mpec example

variable f, x1, x2, y1, y2;
positive variable y1;
y2.lo = -1;
y2.up =  1;

equations cost, g, h1, h2;

cost..  f =E= x1 + x2;
g..     sqr(x1) + sqr(x2) =L= 1;
h1..    x1 =G= y1 - y2 + 1;
h2..    x2 + y2 =N= 0;

model example / cost, g, h1.y1, h2.y2 /;
solve example using mpec min f;

Note that the equation cost is used to define \(f\), the constraint g defines the function \(g\), and \(h\) is defined by h1 and h2. The complementarity constraints utilize the standard GAMS convention of specifying the orthogonality relationship between \(h\) and \(y\) in the model statement. The interpretation of the "." relies on the bounds \(a\) and \(b\) that are specified using positive, negative, or lo and up keywords in GAMS. Note that since h2 really specifies a function \(h_2\) and not a constraint \(h_2(x,y) = 0\), we use the GAMS syntax =N= to ensure this is clear here. Since the relationships satisfied by \(h_1\) and \(h_2\) are determined by the bounds, =G= could also be replaced by =N= in h1.

In describing the various reformulations for (6), it is convenient to partition the \(y\) variables into free \(\mathcal{F}\), lower bounded \(\mathcal{L}\), upper bounded \(\mathcal{U}\) and doubly bounded \(\mathcal{B}\) variables respectively, that is:

\[ \mathbf{B} := \left\{ {y = (y_\mathcal{F},y_\mathcal{L},y_\mathcal{U},y_\mathcal{B})} : {a_\mathcal{L} \leq y_\mathcal{L},\; y_\mathcal{U} \leq b_\mathcal{U},\; a_\mathcal{B} \leq y_\mathcal{B} \leq b_\mathcal{B}} \right\}. \]

We will assume (without loss of generality) that \(a_\mathcal{B} < b_\mathcal{B}\). If \(a_i = b_i\) then (6) holds trivially for the index \(i\) and we can remove the constraint \(h_i\) and its corresponding (fixed) variable \(y_i\) from the model. The complementarity condition for variables in \(y_i \in \mathcal{F}\) is simply the equality \(h_i(x,y) = 0\) so these equality constraints are moved directly into the NLP constraints \(g\) of the original model as equalities. Thus, NLPEC needs only to treat the singly-bounded variables in \(\mathcal{L}\) and \(\mathcal{U}\) and the doubly-bounded variables in \(\mathcal{B}\). In the above example, \(\mathcal{L} = \{ 1 \}\), \(\mathcal{U} = \emptyset\) and \(\mathcal{B} = \{ 2 \}\).

Product reformulations

Product reformulations all involve products of \(y_i\) with \(h_i\), or products of \(y_i\) with some auxiliary or slack variables that are set equal to \(h_i\). The underlying point is that the constraints (3) are entirely equivalent to the following system of equalities and inequalities:

\begin{equation} \tag{7} \begin{array}{c} w_\mathcal{L} = h_\mathcal{L}(x,y),\; a_\mathcal{L} \leq y_\mathcal{L},\; w_\mathcal{L} \geq 0 \text{ and } (y_\mathcal{L} - a_\mathcal{L})^T w_\mathcal{L} = 0 \\ v_\mathcal{U} = -h_\mathcal{U}(x,y),\; y_\mathcal{U} \leq b_\mathcal{U},\; v_\mathcal{U} \geq 0 \text{ and } (b_\mathcal{U} - y_\mathcal{U})^T v_\mathcal{U} = 0 \\ w_\mathcal{B} - v_\mathcal{B} = h_\mathcal{B}(x,y), \; a_\mathcal{B} \leq y_\mathcal{B} \leq b_\mathcal{B},\; w_\mathcal{B} \geq 0,\; v_\mathcal{B} \geq 0 \\ (y_\mathcal{B} - a_\mathcal{B})^T w_\mathcal{B} = 0,\; (b_\mathcal{B} - y_\mathcal{B})^T v_\mathcal{B} = 0 . \end{array} \end{equation}

Note that each inner product is a summation of products of nonnegative terms: a slack variable and the difference between a variable and its bound. In each of these products, either the slack variable or its complement must be zero in order to have a solution. Complementarity is forced by the multiplication of these two terms. The above reformulation is specified using option reftype mult.

There are a number of variations on this theme, all of which can be specified via an options file. All of the inner products could be put into the same equation, left as in (7) above, or broken out into individual products (one for each \(i \in \mathcal{L}\cup\mathcal{U}\), two for each \(i \in \mathcal{B}\)). For example, the complementarity constraints associated with lower bounded variables involve nonnegativity of \(w_\mathcal{L}\), \(y_\mathcal{L} \geq a_\mathcal{L}\) and either of the following alternatives:

\[ (y_\mathcal{L} - a_\mathcal{L})^T w_\mathcal{L} = \sum{(i \in \mathcal{L}} (y_i - a_i) w_i = 0 \]

or

\[ (y_i - a_i) w_i = 0,\; i = 1,\ldots,m \]

These different levels of aggregation are chosen using option aggregate none|partial|full.

Since all of the inner products in (7) involve nonnegative terms, we can set the inner products equal to zero or set them \(\leq\) 0 without changing the feasible set. To choose one or the other, use the option constraint equality|inequality.

As a concrete example, consider the option file

reftype mult
aggregate none
constraint inequality

applied to the simple example given above. Such an option file generates the nonlinear programming model:

\begin{equation} \tag{8} \begin{array}{rc} \displaystyle \min_{x_1,x_2,y_1,y_2,w_1,w_2,v_2} & x_1 + x_2 \\ \text{subject to} & x_1^2 + x_2^2 \leq 1 \\ & w_1 = x_1 - y_1 + y_2 - 1, w_1\geq 0, y_1 \geq 0 \\ & w_1 y_1 \leq \mu \\ & w_2 - v_2 = x_2 + y_2, w_2,v_2 \geq 0, y_2 \in [-1,1] \\ & (y_2 + 1) w_2 \leq \mu,\; (1-y_2) v_2 \leq \mu \end{array} \end{equation}

By default, a single model is generated with the value \(\mu\) set to \(0\). There are many examples (e.g. interior point codes, many LP and NLP packages, published results on reformulation approaches to MPEC) that illustrate the value of starting with a "nearly-complementary" solution and pushing the complementarity gap down to zero. For this reason, the inner products in (7) above are always set equal to (or \(\leq\)) a scalar \(\mu\) instead of zero. By default \(\mu\) is zero, but options exist to start \(\mu\) at a positive value (e.g. InitMu 1e-2), to decrease it by a constant factor in a series of looped solves (e.g. NumSolves 4, UpdateFac 0.1), and to solve one last time with a final value for \(\mu\) (e.g. FinalMu 0). If the following lines are added to the option file

initmu 1.0
numsolves 4

then five consecutive solves of the nonlinear program (8) are performed, the first one using \(\mu = 1\) and each subsequent solve dividing \(\mu\) by 10 (and starting the NLP solver at the solution of the previous model in this sequence).

As a final example, we use a combination of these options to generate a sequence of nonlinear programs whose solutions attempt to trace out the "central path" favored by interior point and barrier algorithms:

reftype mult
constraint equality
initmu 1.0
numsolves 4
updatefac 0.1
finalmu 1e-6

produces 6 nonlinear programs of the form

\[ \begin{array}{rc} \displaystyle \min_{x_1,x_2,y_1,y_2,w_1,w_2,v_2} & x_1 + x_2 \\ \text{subject to} & x_1^2 + x_2^2 \leq 1 \\ & w_1 = x_1 - y_1 + y_2 - 1, w_1 \geq 0, y_1 \geq 0 \\ & w_1 y_1 = \mu \\ & w_2 - v_2 = x_2 + y_2, w_2, v_2 \geq 0, y_2 \in [-1,1],\; (y_2 + 1) w_2 = \mu,\; (y_2-1) v_2 = \mu \end{array} \]

for values of \(\mu = 1,0.1,0.01,0.001,0.0001\) and \(1e-6\).

Slacks and doubly bounded variables

Slack variables can be used to reduce the number of times a complex nonlinear expression appears in the nonlinear programming model, as was carried out in (7). For a simpler illustrative example the NCP constraints (5) are equivalent to the constraints:

\[ w_i = h_i(x,y), 0 \leq w_i, 0 \leq y_i \text{ and } y_i w_i = 0, i=1,\ldots,m \]

This reformulation has an additional equality constraint, and additional variables \(w\), but the expression \(h_i\) only appears once. There are cases when this formulation will be preferable, and the simple option slack none|positive controls the use of the \(w\) variables.

When there are doubly bounded variables present, these two slack options work slightly differently. For the positive case, the reformulation introduces two nonnegative variables \(w_i\) and \(v_i\) that take on the positive and negative parts of \(h_i\) at the solution as shown in (7). Since this is the default value of the option slack, the example (8) shows what ensues to both singly and doubly bounded variables under this setting.

For the case slack none, Scholtes proposed a way to use a multiplication to force complementarity that requires no slack variables:

\begin{equation} \tag{9} h_i \ \ \perp \ \ a_i \leq y_i \leq b_i \iff \\ a_i \leq y_i \leq b_i,\; (y_i - a_i) h_i \leq \mu,\; (y_i - b_i) h_i \leq \mu \end{equation}

Note that unlike the inner products in Section Reformulation, we can expect that one of the inequalities in (9) is unlikely to be binding at a solution (i.e. when \(h_i\) is nonzero). Therefore, we cannot use an equality in this reformulation, and furthermore the products must not be aggregated. Thus, if you use this option, the reformulation automatically enforces the additional options constraint inequality and aggregate none on the doubly bounded variables, even if the user specifies a conflicting option. Thus the option file

reftype mult
slack none

results in the model

\[ \begin{array}{rc} \displaystyle \min_{x_1,x_2,y_1,y_2} & x_1 + x_2 \\ \text{subject to} & x_1^2 + x_2^2 \leq 1 \\ & x_1 - y_1 + y_2 - 1 \geq 0, y_1 \geq 0 \\ & (x_1 - y_1 + y_2 - 1) y_1 = \mu \\ & y_2 \in [-1,1],\; (y_2 + 1)(x_2 + y_2) \leq \mu,\; (y_2-1) (x_2 + y_2) \leq \mu \end{array} \]

Note that the complementarity constraint associated with \(y_1\) is an equality (the default) while the constraints associated with \(y_2\) are inequalities for the reasons outlined above.

In the case of doubly bounded variables, a third option is available for the slack variables, namely slack one. In this case, only one slack is introduced, and this slack removes the need to write the function \(h_i\) twice in the reformulated model as follows:

\[ h_i(x,y) \ \ \perp \ \ a_i \leq y_i \leq b_i \iff a_i \leq y_i \leq b_i,\; w_i = h_i(x,y),\; (y_i - a_i) w_i \leq \mu,\; (y_i - b_i) w_i \leq \mu \]

Note that the slack variable \(w\) that is introduced is a free variable. It is not known before solving the problem whether \(w_i\) will be positive or negative at the solution.

We take this opportunity to introduce a simple extension to our option mechanism, namely the ability to set the options for singly and doubly bounded variables differently. For example, the option file

reftype mult
slack positive one

sets the option slack positive for the singly bounded variables and the option slack one for the doubly bounded variables resulting in the model

\[ \begin{array}{rc} \displaystyle \min_{x_1,x_2,y_1,y_2,w_1,w_2} & x_1 + x_2 \\ \text{subject to} & x_1^2 + x_2^2 \leq 1 \\ & w_1 = x_1 - y_1 + y_2 - 1, w_1 \geq 0, y_1 \geq 0 \\ & w_1 y_1 = \mu_1 \\ & w_2 = x_2 + y_2,\; y_2 \in [-1,1],\; (y_2 + 1) w_2 \leq \mu_2,\; (y_2-1) w_2 \leq \mu_2 \end{array} \]

Additional options such as

initmu 1.0 3.0
numsolves 2
updatefac 0.1 0.2

allow the values of \(\mu\) for the singly and doubly bounded variables to be controlled separately. In this case \(\mu_1\) takes on values of \(1\), \(0.1\) and \(0.01\), while \(\mu_2\) takes on values \(3.0\), \(0.6\) and \(0.12\) in each of the three nonlinear programming models generated.

NCP functions

An NCP-function is a function \(\phi(r,s)\) with the following property:

\[ \phi(r,s) = 0 \Longleftrightarrow r \geq 0, s \geq 0, rs = 0 \]

Clearly, finding a zero of an NCP-function solves a complementarity problem in \((r,s)\). We can replace the inner products of nonnegative vectors in (7) with a vector of NCP functions whose arguments are complementary pairs, e.g. \((y_\mathcal{L} - a_\mathcal{L})^Tw_\mathcal{L} = 0\) becomes \(\phi(y_i - a_i,w_i) = 0, i \in \mathcal{L}\) and arrive at another way to treat the complementarity conditions. Note that an NCP function forces both nonnegativity and complementarity, so constraints to explicitly force nonnegativity are not required, though they can be included.

Examples of NCP functions include the min function, min(r,s), and the Fischer-Burmeister function

\[ \phi(r,s) = \sqrt{r^2 + s^2} - r - s \]

There is no requirement that an NCP function be nonnegative everywhere (it may be strictly negative at some points), so there is little point in setting the option constraint; it will automatically take on the value constraint equality. NCP functions cannot be aggregated, so the aggregate option will always be set to none.

Since the arguments to the NCP functions are going to be nonnegative at solution, we cannot use the functions \(h_i\) directly in the case of doubly-bounded variables. We must use slacks \(w - v = h_i\) to separate \(h_i\) into its positive and negative parts (but see Section Doubly bounded variables below). The slacks can be positive or free, since the NCP function will force positivity at solution. For the singly-bounded variables, slacks are optional, and can also be positive or free.

Both of the NCP functions mentioned above suffer from being non-differentiable at the origin (and at points where \(r=s\) for the \(\min\) function). Various smoothed NCP-functions have been proposed that are differentiable. These smooth functions are parameterized by \(\mu\), and approach the true NCP-function as the smoothing parameter approaches zero. For example, the Fischer-Burmeister function includes a perturbation \(\mu\) that guarantees differentiability:

\begin{equation} \tag{10} \phi_{FB}(r,s) := \sqrt{r^2 + s^2 + 2\mu} - (r+s). \end{equation}

You can choose these particular NCP functions using option RefType min|FB|fFB. The difference between the last two is that RefType FB writes out GAMS code to compute the function \(\phi_{FB}\), while RefType fFB makes use of the GAMS intrinsic function NCPFB(r,s,mu) that computes \(\phi_{FB}\) internally. In general, using the GAMS intrinsic function should work better since the intrinsic can guard against overflow, scale the arguments before computing the function, and use alternative formulas that give more accurate results for certain input ranges.

As an example, the option file

reftype fFB
slack free
initmu 1e-2

generates the reformulation

\[ \begin{array}{rc} \displaystyle \min_{x_1,x_2,y_1,y_2,w_1,w_2,v_2} & x_1 + x_2 \\ \text{subject to} & x_1^2 + x_2^2 \leq 1 \\ & w_1 = x_1 - y_1 + y_2 - 1 \\ & \phi_{FB}(w_1,y_1,\mu) = 0 \\ & w_2 - v_2 = x_2 + y_2 \\ & \phi_{FB}(y_2 + 1,w_2,\mu) = 0,\; \phi_{FB}(1-y_2,v_2,\mu) = 0 \end{array} \]

with a value of \(\mu = 0.01\). Following a path of solutions for decreasing values of \(\mu\) is possible using the options discussed above.

Each of the two arguments to the NCP function will be nonnegative at solution, but for each argument we have the option of including a nonnegativity constraint explicitly as well. This results in the 4 values for the option NCPBounds none|all|function|variable. When no slacks are present, this option controls whether to bound the function \(h_i\) as well as including it in the NCP function, e.g. \(h_i \geq 0, \phi(h_i,y_i-a_i) = 0\). When slacks are present, we require that the slack setting be consistent with the bound setting for the function argument to the NCP function, where NCPBounds none|variable is consistent with free slack variables and NCPBounds all|function is consistent with positive slack variables.

Thus, the option file

reftype min
slack positive
NCPBounds function

generates the reformulation

\[ \begin{array}{rc} \displaystyle \min_{x_1,x_2,y_1,y_2,w_1,w_2,v_2} & x_1 + x_2 \\ \text{subject to} & x_1^2 + x_2^2 \leq 1 \\ & w_1 = x_1 - y_1 + y_2 - 1, w_1 \geq 0 \\ & \min(w_1,y_1) = \mu \\ & w_2 - v_2 = x_2 + y_2, w_2, v_2 \geq 0 \\ & \min(y_2 + 1,w_2) = \mu,\; \min(1-y_2,v_2) = \mu \end{array} \]

The NCPBounds function option means that the variable argument to the NCP function (in this case \(y\)) does not have its bounds explicitly enforced. It should be noted that this nonlinear program has nondifferentiable constraints for every value of \(\mu\). For this reason, the model is constructed as a dnlp model (instead of an nlp model) in GAMS.

A smoothed version of the min function was proposed by Chen & Mangasarian:

\begin{equation} \tag{11} \phi_{CM}(r,s) := r - \mu \log(1 + \exp((r-s)/\mu)) . \end{equation}

This function is not symmetric in its two arguments, so \(\phi_{CM}(r,s) \neq \phi_{CM}(s,r)\). For this reason, we distinguish between the two cases. Unlike the Fischer-Burmeister function \(\phi_{FB}\), \(\phi_{CM}\) is not defined in the limit (i.e. for \(\mu = 0\)) if you use GAMS code to compute it. However, the GAMS intrinsic NCPCM(r,s,mu) handles this limit case internally. The option RefType CMxf|CMfx|fCMxf|fCMfx chooses a reformulation based on the function \(\phi_{CM}\). Again, the last two choices use the GAMS intrinsic function.

Doubly bounded variables

Like the mult reformulation (7), reformulations using NCP functions are appropriate as long as we split the function \(h_i\) matching a doubly-bounded variable into its positive and negative parts \(w_i - v_i = h_i\). To avoid this, Billups has proposed using a composition of NCP functions to treat the doubly-bounded case:

\begin{equation} \tag{12} h_i \ \ \perp \ \ a_i \leq y_i \leq b_i \iff \\ \phi_{FB}(y_i - a_i, \phi_{FB}(b_i - y_i, -h_i)) = 0 \end{equation}

Use option RefType Bill|fBill to choose such a reformulation for the doubly-bounded variables. The first option value writes out the function in explicit GAMS code, while the second writes it out using the GAMS intrinsic function NCPFB.

Penalty functions

All of the reformulations discussed so far have reformulated the complementarity conditions as constraints. It is also possible to treat these by moving them into the objective function with a penalty parameter \(1/\mu\): as \(\mu\) goes to zero, the relative weight placed on complementarity increases. Ignoring the NLP constraints, we can rewrite the original MPEC problem as

\begin{equation} \tag{13} \min_{x \in \mathbf{R}^n, y \in \mathbf{R}^m} f(x,y) + \frac{1}{\mu} ((y_\mathcal{L} - a_\mathcal{L})^T w_\mathcal{L} + (b_\mathcal{U} - y_\mathcal{U})^T v_\mathcal{U} + (y_\mathcal{B} - a_\mathcal{B})^T w_\mathcal{B} + (b_\mathcal{B} - y_\mathcal{B})^T v_\mathcal{B}) \end{equation}

subject to the constraints

\begin{equation} \tag{14} \begin{array}{c} g(x,y) \leq 0\\ w_\mathcal{L} = h_\mathcal{L}(x,y),\; a_\mathcal{L} \leq y_\mathcal{L},\; w_\mathcal{L} \geq 0\\ v_\mathcal{U} = -h_\mathcal{U}(x,y),\; y_\mathcal{U} \leq b_\mathcal{U},\; v_\mathcal{U} \geq 0 \\ w_\mathcal{B} - v_\mathcal{B} = h_\mathcal{B}(x,y) \; a_\mathcal{B} \leq y_\mathcal{B} \leq b_\mathcal{B},\; w_\mathcal{B} \geq 0, v_\mathcal{B} \geq 0 \end{array} \end{equation}

Choose this treatment using option refType penalty. The options aggregate and constraint are ignored, since the inner products here are all aggregated and there are no relevant constraints. It is possible to do a similar reformulation without using slacks, so the options slack none|positive can be used in conjunction with this reformulation type.

The following option file shows the use of the penalty reformulation, but also indicates how to use a different reformulation for the singly and doubly bounded variables:

reftype penalty mult
slack none *
initmu 1.0
numsolves 2
updatefac 0.1 0.2

The "*" value allows the slack option to take on its existing value, in this case positive. Applied to our simple example given above, such an option file generates the nonlinear programming model:

\[ \begin{array}{rc} \displaystyle \min_{x_1,x_2,y_1,y_2,w_2,v_2} & x_1 + x_2 + \frac{1}{\mu_1} y_1 (x_1 - y_1 + y_2 - 1) \\ \text{subject to} & x_1^2 + x_2^2 \leq 1 \\ & x_1 - y_1 + y_2 - 1 \geq 0, y_1 \geq 0 \\ & w_2 - v_2 = x_2 + y_2, w_2,v_2 \geq 0, y_2 \in [-1,1] \\ & (y_2 + 1) w_2 \leq \mu_2,\; (1-y_2) v_2 \leq \mu_2 \end{array} \]

The penalty parameter \(\mu_1\) is controlled separately from the doubly bounded constraint parameter \(\mu_2\). For consistency with other options, the penalty parameter in the objective is \(1/\mu\) meaning that as \(\mu_1\) tends to zero, the penalty increases. The option initmu has only one value, so both the singly and doubly bounded \(\mu\) values are initialized to \(1\). In the above example, three solves are performed with \(\mu_1 = 1, 0.1\) and \(0.01\) and \(\mu_2 = 1, 0.2\) and \(0.04\).

Testing for complementarity

In some cases a solution to the reformulated model may not satisfy the complementarity constraints of the original MPEC, e.g. if a large penalty parameter is used in the reformulation. It can also happen that the solution tolerances used in the NLP solver allow solutions with small error in the NLP model but large error in the original MPEC. For example if \(x = f(x) = .001\) then the NLP constraint \(xf(x) = 0\) may satisfy the NLP feasibility tolerance but it's not so easy to claim that either \(x\) or \(f(x)\) is zero. The NLPEC solver includes a check that the proposed solution does in fact satisfy the complementarity constraints. The complementarity gap is computed using the definition common to all GAMS MCP solvers in computing the objval model attribute for an MCP model. The tolerance used for this complementarity gap can be adjusted using the testtol option.

Options

For details on how to create and use an option file, see the introductory chapter on solver usage.

For most GAMS solvers, the use of an options file is discouraged, at least for those unfamiliar with the solver. For NLPEC, however, we expect that most users will want to use an options file from the very beginning. NLPEC is as much a tool for experimentation as it is a solver, and as such use of the options file is encouraged.

Option values can take many different types (e.g. strings, integers, or reals). Perhaps the most important option to remember is one with no value at all: the help option. Help prints a list of the available options, along with their possible values and some helpful text. The options file is read sequentially, so in case an option value is set twice, the latter value takes precedence. However, any consistency checks performed on the options values (e.g. RefType fBill cannot be used with aggregate full) are made after the entire options file is read in, so the order in which different options appear is not important, provided the options are not specified twice.

Setting the Reformulation Options

While NLPEC has many options, there is a small set of five options that, taken together, serve to define the type of reformulation used. Listed in order of importance (highest priority items first), these reformulation options are the RefType, slack, constraint, aggregate and NCPBounds options. In some cases, setting the highest-priority option RefType is enough to completely define a reformulation (e.g. RefType penalty in the case of doubly-bounded variables). In most cases though, the lower-priority options play a role in defining or modifying a reformulation. It's useful to consider the reformulation options in priority order when creating option files to define reformulations.

Some of the combinations of the reformulation options don't make sense. For example, the use of an NCP function to force complementarity between its two input arguments requires a separate function for each complementary pair, so setting both RefType min and aggregate full is inconsistent. NLPEC implements consistency checks on the reformulation options using the priority order: Given a consistent setting of the higher priority options, the next-highest priority option is checked and, if necessary, reset to be consistent with the items of higher priority. The end result is a set of consistent options that will result in a working reformulation. NLPEC prints out the pre- and post-checked sets of reformulation options, as well as warning messages about changes made. In case you want to use an option that NLPEC doesn't think is consistent, you can use the NoCheck option: this supresses the consistency checks.

Each of the reformulation options in the table below takes two values - one for the singly-bounded variables in \(\mathcal{L}\cup\mathcal{U}\) and another for the doubly-bounded variables in \(\mathcal{B}\). If one option value appears, it sets both option values. When setting both option values, use an asterisk "*" to indicate no change. So for example, an option file

RefType  fCMxf
RefType  *  fBill

first sets the RefType to fCMxf for all variable types, and then resets the RefType to fBill for doubly-bounded variables.

Reformulation Options

Option Description Default
aggregate controls constraint aggregation
Determines if certain constraints are aggregated or not. E.g. to force w >= 0 and y >= 0 to be complementary we can write either w^T y <= 0 or w_i^T y_i <= 0, for all i.
none: use no aggregation
partial: aggregate doubly-bounded variables separately from others
full: use maximum aggregation possible
none
constraint controls use of equality/inequality
Determines if certain constraints are written down using equalities or inequalities. E.g. to force w >= 0 and y >= 0 to be complementary we can write either w^T y <= 0 or w^T y = 0. This option only plays a role when bounding a quantity whose sign cannot be both positive and negative and which must be 0 at a solution.
equality: use =E= constraints
inequality: use =L= constraints
equality
NCPBounds sets explicit bounds on arguments of NCP functions
Determines which of the two arguments to an NCP function Phi(r,s) are explicitly constrained to be nonnegative. The explicit constraints are in addition to those imposed by the constraint Phi(r,s) = 0, which implies nonnegativity of r and s.
none: no explicit bounds
function: explicit bound on function/slack argument
variable: explicit bound on variable argument
all: explicit bound on both function and variable arguments
none
refType reformulation type
Determines the type of reformulation used. Our notation and descriptions are taken from a special case of the MPEC, the NCP: find x >= 0, f(x) >= 0, x^T f(x) = 0.
mult: inner product <x,f> = 0
min: NCP function min(x,f)
CMxf: Chen-Mangasarian NCP function, explicit
CMfx: Chen-Mangasarian NCP function, explicit
fCMxf: Chen-Mangasarian NCP function, intrinsic
fCMfx: Chen-Mangasarian NCP function, intrinsic
FB: Fischer-Burmeister NCP function, explicit
fFB: Fischer-Burmeister NCP function, intrinsic
FB_neg: Fischer-Burmeister NCP function negated, explicit
fFB_neg: Fischer-Burmeister NCP function negated, intrinsic
Bill: Billups function for doubly-bounded variables, explicit
fBill: Billups function for doubly-bounded variables, intrinsic
penalty: weighted penalization of non-complementarity in objective
median: median function for doubly-bounded variables, explicit
fVUsin: Veelken-Ulbrich NCP function (smoothed min), intrinsic
fVUpow: Veelken-Ulbrich NCP function (smoothed min), intrinsic
mult
slack control use of slacks for function values
Determines if slacks are used to treat the functions h_i. For single-bounded variables, we use at most one slack (either free or positive) for each h_i. For doubly-bounded variables, we can have no slacks, one slack (necessarily free), or two slacks (either free or positive) for each h_i.
none: no slacks will be used
free: free slacks will be used
positive: non-negative slacks will be used
one: one free slack will be used for each h_i in the doubly bounded case
positive

General Options

Option Description Default
allSolves do all solves in a loop regardless of previous failure
In case multiple (looped) solves are specified, the default is to skip subsequent solves when any solve terminates without getting a solution. Setting this flag removes the check and all solves are done, regardless of previous failures.
0
dotGams name of gams source file for scalar model auto
dumpValid dump valid reformulation options to a GDX file and exit 0
equReform outdated and deprecated
Range: {0, ..., 33}
0
finalMu final value of parameter mu
If specified, an extra solve is carried out with mu set to this value. Can be set independently for singly and doubly bounded variables.
none
initMu initial value of parameter mu
A single solve of the nonlinear program is carried out for this value. Note that mu must be positive for some settings of reftype, e.g. penalty. Can be set independently for singly and doubly bounded variables.
0
initSLo lower bound for artificials added to the problem
Range: [-∞, ∞]
0
initSUp upper bound for artificials added to the problem
Range: [-∞, ∞]
+inf
noCheck do not check consistency of reformulation options 0
numSolves number of looped solves
This should be set in conjunction with the updateFac option, so that the mu values are lowered successively.
0
parmFile extra GAMS options for running scalar model
subSolver controls what subsolver to run
If this option is not specified, the usual GAMS rules for selecting the solver to run are used.
auto
subSolverOpt optfile value to pass to the subsolver 0
terminate terminate after generating scalar GAMS source code 0
testTol tolerance for complementarity check in MPEC/MCP 1e-005
updateFac update factor for mu
The factor that multiplies mu before each of the extra solves triggered by the numsolves option. Can be set independently for singly and doubly bounded variables.
Range: [1e-280, 1.0]
1e-1

The Outdated equreform Option

In the early versions of NLPEC the only way to set the reform type was via the equreform option. Each valid equreform value represented a preselected combination of the options from Section Setting the Reformulation Options. This made it difficult to experiment with combinations not preselected, so the options in Section Setting the Reformulation Options were added. Be default, the equreform option has value 0 and is not used. To get the old behavior, set equreform to a positive value - this will force the options in Section Setting the Reformulation Options to be ignored. The general options in Section General Options are used no matter how the reformulation type is selected - via RefType or equreform.

Option Description Default
equreform Old way to set the type of reformulation used. 0

The values allowed for equreform and their implications are given by the following table.

Open Architecture

In this section we describe the architecture of the NLPEC solver, i.e. the way the solver is put together. This should be useful to anybody using NLPEC for experiments or to those wanting to know the details of how NLPEC works.

The foundation for the NLPEC solver is the software library (also used in the GAMS/CONVERT solver) that allows us to write out a scalar GAMS model that is mathematically equivalent to the original, or to write out selected pieces of such a model. Using this software, NLPEC creates a GAMS NLP model using one of the reformulation strategies from Section Reformulation. This model may contain many new variables and/or equations, but it will surely contain the (non)linear expressions defining the original model as well. Once the scalar model has been created, NLPEC calls GAMS to solve this model, using the current NLP solver. The option parmFile can be used to pass on additional options to this GAMS job. After the model has solved, NLPEC reads the NLP solution, extracts the MPEC solution from it, and passes this MPEC solution back to GAMS as it terminates.

There are a number of advantages to this architecture. First, its openness makes it easy to see exactly what reformulation is being done. The intermediate scalar GAMS NLP model can be made available after the run by either saving the scratch directory (i.e. run with keep=1) or using the dotGams option to select an alternate file name. This intermediate model contains all the details of the reformulation. It can be used for debugging in case things didn't work out as expected. It is also possible to modify this file to do some quick and dirty experiments with similar reformulation strategies. Another advantage is the variety of NLP solvers that can be plugged in to solve the reformulated model. There is no need to program (and debug) an interface to an NLP package to run experiments with an NLP solver - the existing GAMS link is all that is needed. It is also easy to experiment with non-default solver options that may be more appropriate for reformulated MPEC models or for a particular choice of reformulation.
